FANUC Overtravel (OT) Alarm Codes

Alarm CodeMessageDescription
500 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check I.
(Parameter No.1320 or 1326 NOTE)
501 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check I.
(Parameter No.1321 or 1327 NOTE)
502 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check II.
(Parameter No.1322 )
503 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check II.
(Parameter No.1323)
504 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check III.
(Parameter No.1324 )
505 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check III.
(Parameter No.1325 )
506 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side hardware OT.
507 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–8) – side hardware OT.
508 INTERFERENCE: +n
(T series (two–path control))
A tool moving in the positive direction along the n axis has fouled another
tool post.
509 INTERFERENCE: –n
(T series (two–path control))
A tool moving in the negative direction along the n axis has fouled another
tool post.
510 OVER TRAVEL: +n Alarm for stroke check prior to movement. The end point specified in a
block falls within the forbidden area defined with the stroke check in the
positive direction along the N axis. Correct the program.
511 OVER TRAVEL: –n Alarm for stroke check prior to movement. The end point specified in a
block falls within the forbidden area defined with the stroke check in the
negative direction along the N axis. Correct the program.
514 INTERFERENCE : +n The rotation area interference check function found interference on the
plus side of the n axis.
515 INTERFERENCE : –n The rotation area interference check function found interference on the
minus side of the n axis.
